Products Description
CNC Sheet Metal Punching Machine is a mechanical turret punching machine produced by a China factory. It is equipped with a CNC controller, featuring a high degree of automation and excellent performance. This machine is suitable for various sheet metal processing, such as punching, shearing, embossing, bending, etc. The position accuracy of this machine is up to ±0.05mm. The maximum sheet size it can process is 2000mm*5000mm. The maximum punching speed is 200HPM and the maximum punching force is 300KN, while the maximum stroke is 100mm. This CNC turret punching machine is reliable and durable, with a great cost-performance ratio, making it an ideal choice for sheet metal processing.
Features:
Product Name: CNC Sheet Metal Punching Machine
Weight: 8000KG
Dimension: 5000mm*2500mm*2500mm
Function: Good quality stamping press machine, Automatic Turret Puncher, Sheet Metal Punching Machine
Repeatability: ±0.03mm
CNC System: Schneider System
Applications:
The CNC Sheet Metal Punching Machine with the Brand Name of AiTe and Model Number of MD-300 has passed the CE ISO90001 certification, and it is made in China. It has the minimum order quantity of 1 Set, and the price range is from $30000 to $90000. The packaging is seaworthy, and the delivery time is 30 working days after receiving the 30% deposit. The payment terms are TT30% advance, balance 70% before shipment, and the supply ability is 1800sets/year. The repeatability of this product is ±0.03mm.
This CNC Sheet Metal Punching Machine has a maximum punching force of 300KN, the maximum punching speed of 200HPM, and the max sheet thickness of 6.5mm. It is an ideal choice for the industrial use because it is an automatic turret puncher, which is capable of stamping metal plate. It is suitable for the wide range of applications in sheet metal fabrication.
Customization:
Customized CNC Sheet Metal Punching Machine from AiTe Brand
AiTe Brand CNC Sheet Metal Punching Machine MD-300 is a perfect choice for customers looking for a machine with powerful performance and reliable quality. The product is certified with CE ISO90001, and with minimum order quantity of 1 set, it is sold at competitive price ranging from $30000-$90000. The product is packaged with seaworthy package and delivered within 30 working days after 30% deposit. The payment terms are TT30% advance and 70% before shipment. The machine has a production capacity of 1800 sets per year.
This CNC Sheet Metal Punching Machine MD-300 is equipped with XYZ-123 model and it has a maximum punching speed of 200HPM. Its position accuracy is ±0.05mm and it is equipped with Schneider system and 3 axis number. The machine is an automatic turret puncher with servo motor punching technology and mechanical turret punching.
Technical Parameters:
| Parameter | Value |
| China Factory Punching Machine | XYZ-123 |
| Aliuminum Punching Machine | XYZ-123 |
| Axis Number | 3 |
| Max Sheet Thickness | 6.5mm |
| CNC System | Schneider System |
| Max Sheet Size | 2000mm*5000mm |
| Max Punching Speed | 200HPM |
| Max Punching Force | 300KN |
| Power Supply | 380V/50Hz |
| Dimension | 5000mm*2500mm*2500mm |
| Position Accuracy | ±0.05mm |
